Frame window, ready for installation, tilt window
Made from two-sheet special 1.4301 (AISI 304) stainless steel profile with intermediate special plastic core to prevent thermal conduction, thermally insulated according to EN 10077, Uf = 2.70 W/(m²*K), fittings galvanised, tilt fittings with catch or handle.
Blind frame, circumferential, made from special profile, designed for dowelling into window soffit, including fixing material. Sash frame, made from Z-profile, integrated fittings. Two rebat gaskets. Glazing bead invisibly fastened.
Machine ground surface finish. Dry glazing with insulation glass, without KTW approval
HUBER window with thermo glass and hinged frame F2
Options
- 1.4404 (AISI 316 L) stainless steel
- Secure to prevent forced access according to DIN EN 1627
- Special glazing (e.g. security glass)
- Multi-wing window
- Outside window sill made from stainless steel
- Water chamber window (with drain holes towards the dry side, with wet glazing, KTW approved)
- Other designs available on request
